Turnigy Accucell S60 Smart Charger

TURNIGY continues to lead the way in compact AC battery chargers with the ACCUCELL S60.

This unit has been designed to balance charge battery packs up to 4S and has more than enough capacity too, with a 60W maximum charging current of 6A and a discharge current of 2A.  It has a high-performance micro processor that controls charging and discharging and is suitable for use with all current battery types including LiPo, Lilon, LiFe, NiCd, iHM, PB and the new generation LiHV with a high end voltage of 4.35V.

TURNIGY knows that safety is paramount around battery chargers and like all of their designs the Accucel S60 has many safety features including terminal voltage control, automatic charging current limit, capacity limit, temperature threshold and processing time limit, built in to minimise the risk of overload/overcharging.

The free “Charge Master” software gives you unparalleled ability to operate the S60 charger through your computer. You can monitor pack voltage, cell voltage, resistance and other data during the charging process and view charging data in real-time graphs.

“Charge Master” will prove to be a valuable tool for monitoring battery performance. All you need do is to download the software to your PC and connect a USB cable between the charger and your PC.

So if you are looking for a charger or are thinking of upgrading your old Accucel then the S60 is definitely the charger for you.

Specs:
AC Input Voltage : 100-240V
Display Type: 2x16 LCD Display Backlight Blue
Case Material: Plastic
Controls: Four Buttons
Case Size: 112x100x51mm
Weight: 321g
PC Communications: USB Port for PC Control & Firmware Upgrade
External Port: 2-4S Balance Socket-XH, Temperature Probe Socket, Battery Socket, Micro USB Port for PC.
Delta Peak Detection for NiMH/NiCd: 3-15mV/cell / Default: 4mV/cell
Battery Cutoff Temperature: 20°C/68°F - 80°C/176°F (adjustable)
Charge Voltage: NiMH/NiCd: Delta peak detection
LiPo: 4.18-4.25V/cell
LiHV:4.25-4.35V/cell
LiFe: 3.58-3.7V/cell
LiIon: 4.08-4.2V/cell
Balance Current: 200mA/cell
Reading Voltage Range: 0.1-26.1V/cell
Battery Types/Cells:
LiPo/LiHV/LiFe/LiIon: 2-4cells
NiMH/NiCd: 6-8cells
Pb: 3-6cells
Battery Capacity Range:
NiMH/NiCd: 100-50000mAh
LiPo/LiHV/LiFe/LiIon: 100-50000mAh
Pb: 100-50000mAh
Charge Current: 0.1A-6.0A
Safety Timer: 1-120minutes off
Charge Wattage: 60W
Discharge Current: 0.1A-2.0A
Discharge Cut-off Voltage:
NiMH/NiCd: 0.1-1.1V/cell
LiPo: 3.0-3.3V/cell LiHV: 3.1-3.4V/Cell
LiFe: 2.6-2.9V/cell LiIon: 2.9—3.2V/cell
Pb: 1.8V/cell
Discharge Wattage: 10W
Balance Cells: 2-4 cells
Memory: 10 different charge/discharge profiles
Charge Method: CC/CV for lithium types and lead (Pb) batteries, Delta-peak Sensitivity for NiMH/NiCd.

Includes:
TURNIGY ACCUCELL S60 Charger
Power Cord
18AWG Charging Cable with XT60 Connector
